STS DIN Rail Mounted Single Phase Prepaid Electricity Meter with Class 1.0 Accuracy IP54 Waterproof and 5(60)A Current

STS DIN Rail Mounted Single Phase Prepaid Electricity Meter with Class 1.0 Accuracy IP54 Waterproof and 5(60)A Current

Class 1.0 Accuracy STS Prepaid Electricity Meter

IP54 Waterproof Single Phase Electricity Meter

5(60)A Current DIN Rail Mounted Meter

起源の場所:

湖南省、中国

ブランド名:

Stron

証明:

STS Certificate

モデル番号:

STE18

連絡 ください
引金 を 求め て ください
製品詳細
公称電圧:
220V/230V
動作電圧範囲:
30%~120%UN
わずかな頻度:
50-60Hz
現在:
5(60) A
精度クラス:
クラス1.0(アクティブエネルギー)
IP等級:
IP54
操作温度範囲:
-25℃~70℃
ハイライト:

Class 1.0 Accuracy STS Prepaid Electricity Meter

,

IP54 Waterproof Single Phase Electricity Meter

,

5(60)A Current DIN Rail Mounted Meter

支払いと送料の条件
最小注文数量
1
価格
USD25-USD22 per pc
パッケージの詳細
カートン
受渡し時間
151-20日
支払条件
L/C、T/T、ウェスタンユニオン、ペイパル、アリペイ
供給の能力
10月に0000pcs
製品説明
STS DIN Rail Mounted Single Phase RF Electricity Meter for Sub-metering
Product Overview

The Rail-Type Single-Phase Prepaid Meter is a compact, secure, and highly reliable STS-compliant metering solution designed for modern prepaid energy management. With a DIN-rail mounting structure, encrypted token technology, and robust anti-tamper protection, this meter is ideal for apartments, small commercial units, prepaid projects, and smart utility deployments across Africa, Asia, and developing regions.

Key Features
STS Prepaid System

Supports IEC 62053-21/23, IEC62055-31 encrypted token technology, ensuring secure and transparent energy vending.

Compact DIN-Rail Design

Easy installation in distribution boards, meter boxes, rental units, and compact environments.

Accurate Measurement

Class 1.0 accuracy with stable performance under a wide voltage range.

Multiple Vending Channels
  • Mobile app vending
  • Web portal vending
  • POS terminal
  • USSD/SMS (optional)
  • Utility vending system
Intelligent Load Control

Automatic disconnection when credit runs out, overload trip protection, and configurable load limits.

Strong Anti-Tamper Protection

Detects cover opening, magnetic interference, reverse connection, and bypass attempts.

Communication Options
  • RS485
  • PLC / RF (optional)
  • M-Bus / Modbus
  • Supports integration with AMI/AMR systems
Wide Application Range

Ideal for prepaid energy rollouts, rental properties, hostels, smart housing, and utility projects.

Benefits for Utilities
  • Zero outstanding bills - prepaid system improves revenue collection
  • Faster deployment with DIN-rail compact design
  • Reduced field losses through strong anti-tamper functions
  • Supports mass vending through multiple channels
  • Easy integration with existing STS vending platforms
